<span style="color: #ff0000"><span style="font-size: 18.0px"><strong><span style="font-family: times new roman , times , serif">4 Road& 16 Road Servo control Board:</span></strong></span></span>
<strong><span style="font-family: times new roman , times , serif"><span style="font-size: 18.0px">Features:</span></span></strong>
compatible with arduino;
simultaniously control 4ch DC motor and 16ch servo;
can controlled by wifi (DT-06), Bluetooth (HC-06), and PS2 station;
is the best choice for robot tank car chassis and robot arm;
Module pin description and schematic:
16 road servo and 4 road motor drive board, using TB6612 4 road drive, PCA9685 for 16 road servo control.
Bring out the Arduino UNO I/O pin;
The maximum input voltage of the power supply is 15V/DC;
Reserve Bluetooth & WIFI module sockets;
Reserve PS2 handle socket;
4 road DC motor drive, single-channel maximum drive current 1.2A average / 3.2A peak;
16 road servo drive pin, power supply can be switched by external/internal power supply of jumper cap;
<img src="//ae01.alicdn.com/kf/HTB1qplZbeH2gK0jSZJnq6yT1FXaH.jpg" /><strong><img height="800" src="//ae01.alicdn.com/kf/HTB1H6HxdjfguuRjSszcq6zb7FXa6.jpg" width="800" /><img height="800" src="//ae01.alicdn.com/kf/HTB1BbhJKuOSBuNjy0Fdq6zDnVXaL.jpg" width="800" /><img height="800" src="//ae01.alicdn.com/kf/HTB12Sr3djfguuRjy1zeq6z0KFXao.jpg" width="800" /></strong>
<span style="font-family: times new roman , times , serif"><span style="font-size: 18.0px"><strong>Images:</strong></span></span>
<img src="//ae01.alicdn.com/kf/HTB1mWX0XoLrK1Rjy0Fjq6zYXFXaE.jpg" /><img src="//ae01.alicdn.com/kf/HTB1lRRZXjzuK1RjSsppq6xz0XXaC.jpg" /><img src="//ae01.alicdn.com/kf/HTB1vR0ZXc_vK1RkSmRyq6xwupXaN.jpg" /><img src="//ae01.alicdn.com/kf/HTB1yTbxaIfpK1RjSZFOq6y6nFXa1.jpg" /><img src="//ae01.alicdn.com/kf/HTB1g44ZXfLsK1Rjy0Fbq6xSEXXaG.jpg" /><img src="//ae01.alicdn.com/kf/HTB14o0ZXcnrK1RkHFrdq6xCoFXaG.jpg" /><img src="//ae01.alicdn.com/kf/HTB1ASDwaQvoK1RjSZPfq6xPKFXai.jpg" />
<strong><span style="font-family: times new roman , times , serif"><span style="font-size: 18.0px">Shipping List:</span></span></strong>
- Silver/Golden Tank Chassis: 1 set(9V 150rpm motor)
- UNO R3 development board: 1pcs
- 2/4 road motor 16 road servo driver board: 1pcs
- Bluetooth module/Wifi module: 1pcs(Optional)
- PS2 control kit: 1 set(Optional)
<span style="color: #ff0000"><strong><span style="font-family: times new roman , times , serif"><span style="font-size: 18.0px">Free gift:</span></span></strong></span>
- Copper pillar kit: 1set
- 1860 battery box: 1pcs
- Hexagon wrench: 1set
<span style="font-family: times new roman , times , serif"><span style="font-size: 18.0px"><span style="color: #ff0000">Note:</span></span></span>
- We send the tank chassis color randomly. If you need the specify color, pls leave a message when you order.
- The tank chassis is unassembled. Pls see the manual link: wiki.doit.am or contact us to get the manual.
- Not included the battery.
